This series of products is a complete set of three-phase AC 50hZ power transmission and distribution equipment, which can be equipped with ZN85-40.5 high-voltage AC vacuum circuit breaker and other circuit breaker trolleys. It meets the requirements of GB/T 3906, DL/T404, IEC62271-200 and other standards. It is used to receive and distribute 40.5kV network power and control, protect and monitor the circuit.
Product name:
KYN61-40.5 series metal-enclosed switchgear
Product introduction:
This series of products is a three-phase AC 50hZ power distribution complete set, which can be equipped with ZN85-40.5 high-voltage AC vacuum circuit breaker and other circuit breaker trolleys. It meets the requirements of GB/T 3906, DL/T404, IEC62271-200 and other standards. It is used to receive and distribute 40.5kV network power and control, protect and monitor the circuit.
Product features:
1. The trolleys are interchangeable and easy to maintain.
2. The cabinet adopts CNC sheet metal assembly structure, the cabinet is completely metal armored, and the whole machine has strong deformation resistance.
3. The car and cabinet are accurately positioned and have strong rigidity, and the operation of entering and exiting the car is light and flexible.
4. The cable room can provide ample space for connecting cable heads.
5. The interlocking function is complete, the operation is simple and reliable.
6. Meet the temperature rise requirement of 1.1×2500A.
7. Optional intelligent control monitoring device and electric actuator unit can be used to realize status monitoring, process control and fault alarm of switch cabinet and electric operation of trolley and grounding switch.
