This series of products is suitable for three-phase AC single bus, double bus, and single bus with bypass systems with rated voltage of 3.6-12kV, 50Hz, and rated current of 630A-3150A, for receiving and distributing electric energy. It can meet the use requirements of various types of power plants, substations, and industrial and mining enterprises.
Product name:
XGN2A series fixed AC metal-enclosed switchgear
Product introduction:
This series of products is suitable for three-phase AC single bus, double bus, and single bus with bypass systems with rated voltage of 3.6-12kV, 50Hz, and rated current of 630A-3150A, for receiving and distributing electric energy. It can meet the use requirements of various types of power plants, substations (stations) and industrial and mining enterprises.
Product features:
1. The cabinet body is welded with angle steel, and can also be bolted with steel sections, with steel plate structure applied externally.
2. The cabinet body consists of four independent compartments: busbar room, circuit breaker room, relay room and cable room, and each room is separated by a metal sealing plate.
3. The cover and door are both bent steel plates. During normal operation and maintenance, the door can be opened without tools according to normal operating procedures; during normal operation and maintenance, the cover cannot be opened without tools.
4. The circuit breaker is fixedly installed in the circuit breaker compartment with a pressure relief channel.
5. The inlet and outlet lines can be overhead from the top of the cabinet or from the bottom of the cabinet.
6. The switch cabinet is double-sided maintenance and is not installed against the wall. Lights are installed in the circuit breaker room and the cable room.
7. There is a grounding copper bar parallel to the cabinet width under the front door to ensure that each cabinet is safely and reliably grounded.
