JCZ2-6J(D)/400-4 AC high-voltage vacuum contactor is suitable for 3-6kV, 50-60Hz three-phase power system, for power plants and other industrial and mining enterprises to control high-voltage motors, transformers or capacitors and other loads, with a rated working current of 400A, suitable for frequent operation. When it is used in conjunction with high-voltage fuses or circuit breakers, the expected short-circuit current is 40kA.
Product name:
JCZ2-6J(D)-400-4 AC high-voltage vacuum contactor
Product introduction:
JCZ2-6J(D)/400-4 AC high-voltage vacuum contactor is suitable for 3-6kV, 50-60Hz three-phase power system, for power plants and other industrial and mining enterprises to control high-voltage motors, transformers or capacitors and other loads, with a rated working current of 400A, suitable for frequent operation. When it is used in conjunction with a high-voltage fuse or circuit breaker, the expected short-circuit current is 40kA.
Product features:
This contactor is mainly suitable for KYN18(F-C) cabinets and is suitable for various installation methods; the high and low voltage circuits are arranged in two compartments in front and back, and are driven by equal-arm levers; the positive contactor has a closing and opening status indicator and a counter observation window, and the J-type contactor has a mechanical locking device for the opening position.
