JCZR16-12J(D) series vacuum contactor-fuse combination is suitable for three-phase AC power system with rated voltage of 12kV and rated frequency of 50Hz. It can be assembled in switch cabinet to form F-C circuit and used with integrated protector. It can be used in power plants and industrial and mining enterprises to close and disconnect AC high-voltage motors, transformers, induction furnaces and other loads, and has overload and short-circuit protection functions.
Product name:
JCZR16-12J(D) series vacuum contactor-fuse combination electrical appliances
Product introduction:
JCZR16-12J(D) series vacuum contactor-fuse combination electrical appliances are suitable for three-phase AC power systems with rated voltage of 12kV and rated frequency of 50Hz. They can be assembled in switch cabinets to form F-C circuits and used in conjunction with integrated protectors. They can be used by power plants and industrial and mining enterprises to close and disconnect loads such as AC high-voltage motors, transformers, induction furnaces, etc., and have overload and short-circuit protection functions.
Product features:
1. The chassis, contactor, base, and fuse are arranged in a building block style, which is simple to debug and assemble;
2. During the debugging process of the contactor, only one parameter of overtravel needs to be adjusted to meet the requirements of the mechanical characteristics of the contactor. There are fewer adjustment links, which avoids the influence of human factors; the expansion interface is simple and has a wide range of applications.
