Product name:

Dry-type transformer

Product introduction:

Resin cast dry-type transformers introduce advanced technologies from home and abroad, and independently develop SC(B)10, SC(B)12, SC(B)13, SC(B)14 and SC(B)18 series of thin-insulated dry-type transformers with fillers.

Product features:

Resin cast dry-type transformers SC(B)10, SC(B)12, SC(B)13, SC(B)14 and SC(B)18 series of thin-insulated dry-type transformers with fillers have the following characteristics due to advanced design, high-quality materials, scientific formula, strict process and high-standard testing:

1. Low loss, good power saving effect, economical operation and maintenance-free.

2. Low noise.

3. Small size, light weight and small footprint.

4. Strong heat dissipation capacity.

5. Small partial discharge.

6. High level of short circuit resistance and lightning impact resistance.

7. Flame retardant, explosion-proof, and environmentally friendly. The insulating materials such as glass fiber wound around the coil have self-extinguishing properties, will not produce arcs due to short circuits, and the resin will not produce toxic and harmful gases under high heat.

8. The coil does not absorb moisture, and the core clamp has a special anti-corrosion protective layer. It can operate in 100% relative humidity and other harsh environments, and intermittent operation does not require dehumidification.

9. It is equipped with an intelligent temperature controller with fault alarm, high temperature alarm, over-temperature tripping and black box functions. It can be connected to a computer through an RS485 serial interface and can be centrally controlled.
